• Oracle VM VirtualBox gives you several options to configure networking of your virtual machines. Every Virtual Machine in your VirtualBox can have up to 8 network adapters and these network adapter can be any of the following six hardware types. AMD PCNet PCI II (Am79C970A) AMD PCNet FAST III (Am79C973) This is the default.
• VirtualBox guest OS doesn’t recognize Bluetooth adapter by default. Here is how to enable the built in Bluetooth adapter for Ubuntu guest on Windows host. OS and the version I used are below. Host: Windows 10 Guest: Ubuntu 16.04. I tested the steps with Microsoft Surface Pro 4 and Dell Precision 3510. Here is the list of contents of this post.
• General VBOX Automotive information. Knowledge Base Welcome to the Knowledge Base. Find the most popular, highest rated, and recently updated articles at a glance.

The main driver, vboxguest, provides a generic communication channel ('HGCM', host-guest communication mechanism) between various services which can run on the guest (e.g. Shared folders, shared clipboard, drag and drop) and matching services on the host, as well as providing a few ad-hoc services itself. It also includes an input driver which. At VBox we’re always striving to improve the VBox TV Gateway experience and to deliver the best possible performance. Download the latest VBox software to get the latest product functionality and improvements.

Attachments

Change History

comment:2 Changed 13 years ago by sandervl73

• Status changed from new to closed
• Resolution set to fixed

comment:3 Changed 13 years ago by mludwig

• Status changed from closed to reopened
• Resolutionfixed deleted

comment:4 Changed 13 years ago by frank

• Component changed from other to USB

Vbox Communication Driver Download

Changed 10 years ago by andreweff

• attachmentLogs.tar.gz added

comment:24 Changed 3 years ago by aeichner

• Status changed from reopened to closed
• Resolution set to obsolete
• Description modified (diff)

comment:25 Changed 3 years ago by mrjimenez

• Status changed from closed to reopened
• Resolutionobsolete deleted

comment:27 Changed 3 years ago by MikeStrom

This post shows steps to enable webcams in a VirtualBox guest OS on Windows host. OS/software and the version I used are below. I tested it with Microsoft Surface Pro 4 and Dell Precision 3510.

Host: Windows 10 running VirtualBox 5.2.6.
Guest: Ubuntu Linux 16.04.03 / Mac OS X High Sierra

Here is the steps.

Steps
1. Install ‘Oracle VM VirtualBox Extension Pack’
VirtualBox Extension Pack is required in order to use webcams in VirtualBox guest OS. [1]

1-1. From the VirtualBox Download page, download the extension pack which has the save version as your VirtualBox. In my case, my VirtualBox is v5.2.6 so I downloaded this:
http://download.virtualbox.org/virtualbox/5.2.6/Oracle_VM_VirtualBox_Extension_Pack-5.2.6.vbox-extpack

1-2. Launch “Oracle VirtualBox Manager” and navigate to “File” -> “Preferences”.

1-3. In ‘Preferences’ window, select ‘Extensions’.

1-4. Press ‘Add new package’ icon.

1-5. Select the extension pack and install it.

2. Attaching webcam to guest OS
2-1. Launch the guest OS.

2-2. Launch “Command Prompt” on Windows (Press the Win + R keys, then, type ‘cmd’ and enter) and go to VirtualBox folder.

2-3. List available cameras.

Vbox Communication Driver App

The result should be like below. In case of Surface Pro 4, it has 2 cameras (front and rear).

2-4. Attach webcam(s) you want to use. The number at the end of the line specifies the camera. In this example, if you want to attach the front camera, type like this:

Vbox Communication Driver Job

* Replace “Ubuntu 16.04.3” with your guest OS name.
* You can attach multiple cameras if you want.

3. Verify (Ubuntu Guest)
In case of Linux, cheese is handy to test webcam functionality.

3-1. Install it if it’s not already.

3-2. Then, just type ‘cheese’ to launch. You should be able to see a video stream in newly opened ‘Cheese’ window.

4. Verify (Mac OS Guest)
In Mac OS X, I used ‘Photo Booth’ application to verify.

4-1. Launch ‘Spotlight Search’ by clicking the magnifying glass icon in the upper right corner of the screen.

Vbox Communication Driver Jobs

4-2. Type ‘Photo Booth’ and enter to launch. You should be able to see a video stream in ‘Photo Booth’ window.

References
[1] Oracle VM VirtualBox User Manual 9.7. Webcam passthrough
[2] VirtualBox Download page
[3] Install VirtualBox Extension Pack on Linux and Windows
[4] Connecting a webcam to a VirtualBox guest OS
